NOTE:
Specifications are subject to change without
notice.
4WD: 4-wheel drive.
2WD: 2-wheel drive.
M/T: Manual transmission.
A/T: Automatic transmission.








Brakes
Brake Fluid
Check the brake fluid level by looking at
the reservoir in the engine compartment.
Check that the fluid level is between the
“MAX” and “MIN” lines. If the brake fluid
level ...
Frame Hooks
SX4
Front (1)
SX4 SEDAN
Front (1)
SX4
Rear (2)
SX4 SEDAN
Rear (2)
Side (3)
Frame hooks are provided on the front (1),
rear (2) and side (3) of the vehicle. The
hooks (1) and (2) ...
Service Station Guide
1. Fuel.
2. Engine hood.
3. Tire changing tools.
4. Engine oil dipstick <Yellow>.
5. Automatic transmission fluid dipstick <Red>.
6. Engine coolant.
7. Windshield washer fluid.
8. ...
